Table Cylinders

・Allowable moment improved by up to 240%
・With new high rigidity linear guide
　Allowable moment improved
・The weight has been reduced by incorporating a
　new high rigidity linear guide and piston.
　Weight: 19% reduction (ø20-10 stroke)
・Piping is possible in 3 directions.

・Compact: Overall length: 49.5 mm, Width: 30 mm
・The integration of the linear guide and the cylinder
　allows for reduced design and assembly time.
・Lightweight workpieces such as electronic boards can be stopped,
　positioned, and clamped.
・Port location selectable
・Auto switch mountable on 3 surfaces

・Integrated with a worktable in a compact manner
・An air slide table that is ideal for precision assembly work
・High rigidity and high accuracy
・Smooth movement without looseness has been achieved through the
　adoption of a cross roller guide.
・Compact and lightweight
・Provides twice the output of the existing cylinder through the
　adoption of the dual rod function

・Height: 10% reduction (27 mm: Existing model 30 mm)
・Product weight: 22% reduction (298 g: Existing model 380 g)
・Allowable kinetic energy: 64% improvement
　(0.09 J: Existing model 0.055 J)

・Integrated guide rail and table
・High rigidity and high accuracy has been achieved through
　the adoption of the recirculating linear guide.

・Integrated guide rail and table
・High rigidity and high accuracy has been achieved through the
　adoption of the recirculating linear guide.
・Position of the piping and adjusters can be changed on site according
　to the installation conditions.
・Features installation compatibility with the MXQ series
・Shock absorber also available for ø6
・Soft type/short stroke type shock absorbers (RJ) can be mounted.

・The parallel design of the guide and cylinder creates a slim
　and compact slide.

・This table unit is compatible with a long stroke using a linear guide.
・Table rigidity is constant throughout the entire stroke.

・The integrated front mounting part and table results in a highly
　accurate and rigid top and front mounting surface.
・Traveling parallelism: 0.005 mm
・Height: 10 mm/Width: 20 mm/Length: 43 mm (MXJ4)

・Compact, Lightweight
　Height: 18 mm, Width: 34 mm, Weight: 267 g (MXJ, ø12, 30 mm stroke)
・High Precision
　High-precision linear guide mounted
　Traveling parallelism: 0.005 mm, Mounting parallelism: 0.03 mm
・Auto switch and adjuster can be mounted on the same side.
・Short pitch mounting is possible.

・Cylinder with built-in linear guide, Compact air slide table
