Magnetically Coupled Rodless Cylinders

  • magnetically-coupled-rodless-cylinder-cy3

    Magnetically Coupled Rodless Cylinder CY3

    ・Further improvements have been made on the CY1 series.
    ・The mounting dimensions are the same as those of the CY1 series.
     Upgraded bearing performance and reduced sliding resistance
    ・NPT thread and G thread are available as standard.
  • magnetically-coupled-rodless-cylinder-cy1s

    Magnetically Coupled Rodless Cylinder CY1S

    ・Weight: Max. 15% reduction (0.96 kg: Existing model 1.13 kg)
    ・Overall length: Max. 15 mm shorter (240 mm: Existing model 255 mm)
    ・Improved durability: Lube-retainers are mounted on the internal and
     external surfaces of the cylinder tube to maintain lubrication.
    ・The adjustment bolt improves stroke accuracy/repeatability.
  • magnetically-coupled-rodless-cylinder-cy1

    Magnetically Coupled Rodless Cylinder CY1

    ・This magnetically coupled, space-saving cylinder permits
     a wide range of applications.
  • magnetically-coupled-rodless-cylinder-low-profile-guide-cy1f

    Magnetically Coupled Rodless Cylinder/Low Profile Guide CY1F

    ・Low profile, short body, lightweight
    ・The cylinder and guide are integrated.
  • clean-rodless-cylinder-cyp

    Clean Rodless Cylinder CYPz

    ・Low particle generation transfer in clean environments
