Lock Cylinders/Cylinder with An End Lock

  • lock-cylinders-with-an-end-lock

    Lock Cylinders/Cylinder with An End Lock

    • ・Locking cylinder ideal for intermediate stops, emergency stops, and drop
      　intermediateprevention (Bi-directional lock)
      ・With auto switch (CDNG series: CDNG)
    PDF
  • cylinder-with-lock-mwb-mdwb

    Cylinder with Lock MWB/MDWB

    • ・Lock can be manually operated with a hexagon wrench.
      　Can be easily mounted onto equipment
      ・Separate construction for improved ease of maintenance
      ・Holding force improved by 15%
      ・High stopping accuracy within ±1 mm
      ・Overall length reduced by 18 mm max.
      ・With lock status indication (-X3030)
    PDF
  • lock-unit-mwb-ut

    Lock Unit MWB-UT

    • ・A safety mechanism can be designed if required.
      ・It can also be combined with a wide variety of actuators.
      　Prevents the workpiece from falling
      　Retains the workpiece position even when the air supply is shut
      　off due to power failure, etc.
    PDF
  • cylinder-with-lock-mnb-mdnb

    Cylinder with Lock MNB/MDNB

    • ・Locking cylinder ideal for intermediate stops, emergency stops,
      　and drop prevention (Bi-directional lock)
      ・With auto switch (MDNB series: MDNB, MDNBW)

      ∗ The MNB/MDNB series will be discontinued in October 2022.
      　Please select the MWB/MDWB series.
    PDF
  • cylinder-with-lock-cna2-cdna2

    Cylinder with Lock CNA2/CDNA2

    • ・Locking cylinder ideal for intermediate stops, emergency stops, and
      　drop prevention (Bi-directional lock)
      ・Magnetic field resistant 2-color indicator solid state auto switch
      　D-P3DW□ series mountable
      ・With auto switch (CDNA2 series: CDNA2, CDNA2W)
    PDF
  • cylinder-with-lock-cns-cdns

    Cylinder with Lock CNS/CDNS

    • ・Locking cylinder ideal for intermediate stops, emergency stops,
      　and drop prevention (Bi-directional lock)
      ・With auto switch (CDNS series: CDNS)
    PDF
  • cylinder-with-lock-cls-cdls

    Cylinder with Lock CLS/CDLS

    • ・Locking cylinder ideal for intermediate stops, emergency stops,
      　and drop prevention (Bi-directional lock)
      ・With auto switch (CDLS series: CDLS)
    PDF
  • compact-cy;inder-with-lock-clq-cdlq

    Compact Cylinder with Lock CLQ/CDLQ

    • ・Locking cylinder ideal for drop prevention when the air supply is
      　shut off (Single-directional lock)
      ・With auto switch (CDLQ series: CDLQ)
    PDF
  • compact-cylinder-with-air-cushion-and-lock-rlq-rdlq

    Compact Cylinder with Air Cushion and Lock RLQ/RDLQ

    • ・Locking cylinder ideal for drop prevention when the air supply is shut off
      ・Compact cylinder with a built-in air cushion and lock unit
      　(Single-directional lock)
      ・With auto switch (RDLQ series: RDLQ)
    PDF
  • plate-cylinder-with-lock-mlu-mdlu

    Plate Cylinder with Lock MLU/MDLU

    • ・Locking cylinder ideal for drop prevention when the air supply is shut off
      　(Single-directional lock)
      ・With auto switch (MDLU series: MDLU)
    PDF
  • compact-guide-cylinder-with-lock-mlgp

    Compact Guide Cylinder with Lock MLGP

    • ・Stopping possible at any stroke position
      　Drop prevention when the pressure is decreased or the residual pressure is released
      ・Weight reduced by up to 17% with a shorter guide rod and thinner plate
      　Guide rod: Max. 22 mm shorter (Compared with the existing MLGPM)
      ・Small auto switches or magnetic field-resistant auto switches can be directly
      　mounted on two surfaces.
    PDF
  • mechanically-jointed-hy-rodless-cylinder-with-brake-ml1c

    Mechanically Jointed Hy-rodless Cylinder with Brake ML1C

    • ・A brake mechanism has been compactly integrated into the slide table.
      ・Enables intermediate stops
    PDF
  • cylinder-with-end-lock

    Cylinder with End Lock

    • Drop prevention at stroke end position
      ・When air is discharged at the stroke end position, the lock is activated.
      ・No separate air piping is required for locking.
    PDF
